Laser Marker LM6
Laser Marking Machine
Laser Spot welding machine is ideal for making Precision welding to avoid loss of weight and without impacting the finish of the sample. Also spot welding provides adequate strength to the work piece. Maxsell offers Laser Spot Welding / Soldering machines which is widely used for gold and silver jewellery, golf head, electronic component repair, spot welding for blowhole and so on.
- Ceramic focusing cavity imported from the U.K
- The focusing cavity’s service life
- World-leading automatic light shielding system
- 24-hour continuous operation
Product Details
Product Video
Product Specifications
Description
| Laser Power | Laser Source |
20 / 30 / 50 upto 100W | High Peak Energy, Wide Pulse Width |
| ─── | ─── |
| Laser Diameter | Marking Area |
 M2<1.5 | 110mm x 110mm (options avbl) |
| ─── | ─── |
| Marking Speed | Wavelength |
| Up to 7000 mm/min |   1064 nm |
| ─── | ─── |
| Marking Depth | Cooling System |
| Adjustable | Air Cooling |
| ─── | ─── |
| Marking Software | Power Supply |
User-friendly interface (Useful Industrial functions avbl) | Â 220V, 50/60Hz |
| ─── | ─── |
| Machine Dimensions | Weight: |
| 600mm x 800mm x 1300mm | Â Â Â 80 kg |
| ─── | ─── |
| Operating Temperature: | Warranty |
15°C – 35°C (59°F – 95°F) 15 – 35 Deg Cel with < 90% Humidity |   1 year (Upgrade to 2yrs avbl) |
| Â | Â |
| Â | Â |
| Â | Â |
| Â | Â |
| Â | Â |
| Â | Â |
Is Your Business having Purity Phobia
Use latest XRF Based Gold Testing Machine and Run your Bueinss Confidently
Product Video
Product Specifications
| Detector | Si - Pin Diode Detector |
| Xray Source | W-Target X-Ray tube with Triple stage Cooling |
| Collimator | Most optimum size < 2mm (optional 1mm) |
| Analysis Elements | From AL (13) to U (92) around 79 elements |
| Analysis Range | 1% ~ 99.99% |
| Testing Time | 15 - 60 seconds (User Selectable) |
| High Voltage | 0-50 kV / 0-1 MA |
| Power Supply | 110v - 260 V, 50/60 Hz |
